LLH100US Long Length Urethane Steel Timing Belt H Section 1in Diesel Belting
Diesel Belting long-length H section synchronous belt stock. Supplied in continuous rolls for cut-to-length applications, multi-station drives, and long linear-motion systems.
Key Specifications
- Belt Type: Synchronous Belt
- Section/Profile: H
- Pitch: 0.5 in
- Material: Urethane
- Reinforcement: Steel Cord
- Toothed Sides: 1 (Single-Sided)
- Brand: Diesel Belting
- Part Number: LLH100US
Common Applications
- General industrial timing drives
- Conveyor indexing systems
- Packaging machinery
- Printing and textile equipment
- HVAC blower drives
Notes
- Conforms to RMA/ISO synchronous belt dimensional standards for the specified profile.
- Verify pitch, width, and tooth count against your existing belt or drive design data before ordering.
Need Help Selecting?
Working from pulley diameters and center distance? This product is indexed for our belt sizing tool—enter your drive dimensions and find the correct belt for your application. Contact Texas Belting & Supply for engineering assistance on any drive design question.
